Climax气动注脂泵10-90-OS

The Model 90 series is a 90:1 ratio pump with a totally sealed-in 3-1/4" air motor which will provide efficient operations

at an air inlet pressure of 100 psi, producing 9,000 Ibs. of grease pressure.

Now Available: The Model 120 series is a 120:1 ratio pump with a 4" air motor providing efficient operations at an air

inlet pressure of 100 psi, producing 12,000 lbs. of grease pressure.

The Model 10 & 40 are furnished with 10" pneumatic tires.

All models are furnished with 10 feet of 3/8" ID (std.) 16,000 Ib.-burst High Pressure Grease Hose with 90° swivel on

one end and 1/4" NPT built-in swivel on the other end, 0-15,000 psi Gauge w/protector, air shut-off valve and

necessary Adaptors ready for use.

Specify whether for use on Plug/Ball Valves or Wellhead Gate Valves.

A Climax Plug/Ball Valve Setup includes a 319700 Shutoff Relief Valve and Giant Buttonhead Coupler.

A Climax Wellhead Gate Valve Setup includes a 319700 Shutoff Relief Valve and a 1714 Lube Adapter (1"-14 THD WKM/API).
